//@version=5

//@Shanxia

// NOTE: Only works on 1HR and below and exchange timezones differ so change the session times accordingly.

//

indicator("ICT Session Killzone Boxes & Deviations", "ICT KZs", true, max_lines_count=500, max_boxes_count=500, max_labels_count=500)

// INPUTS

i_time = input.session ('0000-0001:1234567', "New York", tooltip="Different exchanges will have difference time zones so change accordingly.")

i_maxtf = input.int (15, "Max TF", 1, 240, inline="in00")

i_kzmid = input.bool (true, "Session Mid", inline="in00")

i_vline = input.bool (true, "VLine", inline="in3")

i_vcol = input.color (#dfdfdf, "", inline="in3")

i_vstyle = input.string ("Solid", "", options=["Solid", "Dotted", "Dashed"], inline="in3")

i_txtcol = input.color (#5c71af, " Text Col", inline="in3")

i_hline = input.bool (true, "HLine", inline="in1")

i_linecol = input.color (#2d62b6, "", inline="in1")

i_linestyle = input.string ("Dotted", "", options=["Solid", "Dotted", "Dashed"], inline="in1")

i_ex = input.string ("None", "", options=["None", "+1 Day", "Right", "Both"], inline="in1")

i_shf = input.bool (true, "Upcoming Sessions", inline="in4")

i_lonstyle = input.string ("Dotted", " ", options=["Solid", "Dotted", "Dashed"], inline="in4")

i_rshow = input.bool (true, title='Boxes', inline='x1')

i_dev = input.bool (false, 'Deviations', inline='x1')

i_devno = input.int (2 , "", minval=1, inline='x1')

i_pips = input.bool (true, "Box Info | ", inline='x1a')

i_d4 = input.string ( "GMT+10", "DOW Timezone", options=["GMT+0", "GMT+1", "GMT+2", "GMT+3","GMT+4","GMT+5","GMT+6","GMT+7","GMT+8","GMT+9","GMT+10","GMT+11","GMT+12","GMT-1", "GMT-2", "GMT-3","GMT-4","GMT-5","GMT-6","GMT-7","GMT-8","GMT-9","GMT-10","GMT-11","GMT-12"], inline='x1a', tooltip='Time Zone for day of week')

i_bool0 = input.string ("America/New_York", "Time Zone", inline='x7', group="Sessions")

i_btc = input.bool (true, "Box Text", inline="x7", group="Sessions")

i_tcb = input.color (color.new(color.white, 80), "", inline="x7", group="Sessions")

i_transp1 = input.int (85, "Transparency", 0, 100, 1, inline="x7b", group="Sessions" )

i_transp2 = input.int (90, "", 0, 100, 1, inline="x7b", group="Sessions")

i_bool1 = input.bool (true, "", inline='x2', group="Sessions")

i_bool2 = input.bool (true, "", inline='x3', group="Sessions")

i_bool3 = input.bool (true, "", inline='x4', group="Sessions")

i_bool4 = input.bool (true, "", inline='x5', group="Sessions")

i_bool5 = input.bool (true, "", inline='x6', group="Sessions")

cbdr = input.session ('1400-2000', "" , inline='x2', tooltip="CBDR", group="Sessions")

asia = input.session ('2000-0000', "", inline='x3', tooltip="Asia", group="Sessions")

london = input.session ('0200-0500', "", inline='x4', tooltip="London", group="Sessions")

nysesh = input.session ('0700-1000', "", inline='x5', tooltip="New York", group="Sessions")

lcsesh = input.session ('1000-1200', "", inline='x6', tooltip="London Close", group="Sessions")

i_vcbdr = input.color (color.new(#0064ff, 0), "", inline='x2', group="Sessions")

i_vasia = input.color (color.new(#7622ff, 0), "", inline='x3', group="Sessions")

i_vlon = input.color (color.new(#e90000, 0), "", inline='x4', group="Sessions")

i_vny = input.color (color.new(#00acb8, 0), "", inline='x5', group="Sessions")

i_lc = input.color (color.new(#434651, 0), "", inline='x6', group="Sessions")

//INPUTS END

// MISC

nymid = time ("1", i_time, i_bool0)

linestyle = i_linestyle == "Solid" ? line.style_solid : i_linestyle == "Dotted" ? line.style_dotted : line.style_dashed

lonstyle = i_lonstyle == "Solid" ? line.style_solid : i_lonstyle == "Dotted" ? line.style_dotted : line.style_dashed

vstyle = i_vstyle == "Solid" ? line.style_solid : i_vstyle == "Dotted" ? line.style_dotted : line.style_dashed

ex = i_ex == "None" ? extend.none : i_ex == "+1 Day" ? extend.none : i_ex == "Right" ? extend.right : extend.both

htime = i_ex == "+1 Day" ? 172800000 : 86400000

dow = dayofweek == dayofweek.friday ? 259200000 : 86400000

dow2 = dayofweek == dayofweek.friday ? 172800000 : 86400000 //this is for asia coming out of weekend

dow3 = dayofweek == dayofweek.friday ? 172800000 : 0

disp = timeframe.isintraday and timeframe.multiplier <= i_maxtf

// CALC

var openprice = 0.0

if not na(nymid)

 if na(nymid[1])

 openprice := open

 else

 openprice := math.max(open, openprice)

// FUNCTIONS

in_session(sess) =>

 not na(time(timeframe.period, sess, i_bool0))

start_time(sess) =>

 int startTime = na

 startTime := in_session(sess) and not in_session(sess)[1] ? time : startTime[1]

 startTime

is_new_session(res, sess) =>

 t = time(res, sess, i_bool0)

 na(t[1]) and not na(t) or t[1] < t

BarInSession(sess) =>

 time(timeframe.period, sess, i_bool0) != 0



_hline(StartTime, EndTime, Price, Color, Style, Width) =>

 return_1 = line.new(StartTime, Price, EndTime, Price, xloc=xloc.bar_time, extend=extend.none, color=Color, style=Style, width=Width)

pip(x) =>

 forex = syminfo.type == "forex" ? syminfo.mintick * 10 : na

 x / forex



forex = syminfo.type == "forex"

// OBJECTS

var label lb = na

if openprice != openprice[1] and i_hline and disp

 var line lne = na

 line.set_x2(lne, nymid)

 line.set_extend(lne, extend.none)

 lne := line.new(nymid, openprice, nymid + htime + dow3, openprice, xloc.bar_time, ex, i_linecol, linestyle, 2)

 lb := label.new(nymid + htime + dow3, openprice, "NY Midnight Open | " + str.tostring(math.round_to_mintick(openprice)), xloc.bar_time, yloc.price, na, label.style_none, i_txtcol)

 label.delete(lb[1])

f_vline(a, b, d, e, sess) =>

 var line fl1 = na

 var line fl2 = na

 var linefill lf1 = na

 st_vl = timestamp(i_bool0, year, month, sess, a, 00, 00)

 en_vl = timestamp(i_bool0, year, month, sess, b, e, 00)

 fl1 := line.new(st_vl, high, st_vl, low, xloc.bar_time, extend.both, color.new(color.white,100), lonstyle, 1)

 line.delete(fl1[1])

 fl2 := line.new(en_vl, high, en_vl, low, xloc.bar_time, extend.both, color.new(color.white,100), lonstyle, 1)

 line.delete(fl2[1])

 lf1 := linefill.new(fl1, fl2, color.new(d, i_transp2))

 linefill.delete(lf1[1])

 for i = 0 to 100

 if time > line.get_x1(fl2[i])

 line.delete(fl2[i])

 line.delete(fl1[i])

if i_shf and disp

 f_vline(02, 05, i_vlon, 00, dayofmonth)

 f_vline(07, 10, i_vny, 00, dayofmonth)

 f_vline(10, 12, i_lc, 00, dayofmonth)

 f_vline(14, 20, i_vcbdr, 00, dayofmonth)

 f_vline(20, 24, i_vasia, 00, dayofmonth)

 f_vline(02, 05, i_vlon, 00, dayofmonth + 1)

 f_vline(07, 10, i_vny, 00, dayofmonth + 1)

 f_vline(10, 12, i_lc, 00, dayofmonth + 1)

 f_vline(14, 20, i_vcbdr, 00, dayofmonth + 1)

 f_vline(20, 24, i_vasia, 00, dayofmonth + 1)

//BOXES

isnewday = time("D") != time("D")[1]

ictbox(kz, bdcol,txt, x)=>

 sesh = is_new_session('1440', kz)

 var kzlow = 0.0

 var kzhigh = 0.0

 kzbox = box(na)

 bline = line(na)

 bline2 = line(na)

 bline3 = line(na)

 _lbl = label(na)

 kzstart = start_time(kz)

 dow4 = dayofweek(kzstart, i_d4)

 if in_session(kz) and not in_session(kz)[1]

 kzlow := low

 kzhigh := high

 devdiff = kzhigh[1] - kzlow[1]

 tgdist = kzhigh - kzlow

 dol = (time - kzstart) / 2



 if in_session(kz)

 if in_session(kz)[1]

 box.delete(kzbox[1])

 line.delete(bline[1])

 line.delete(bline2[1])

 line.delete(bline3[1])

 label.delete(_lbl[1])

 if low < kzlow

 kzlow := low

 kzlow

 if high > kzhigh

 kzhigh := high

 kzhigh

 if x

 kzbox := box.new(kzstart, kzhigh, time, kzlow, color.new(bdcol, 50), 0, line.style_solid, extend.none, xloc.bar_time, color.new(bdcol,i_transp1), i_btc ? txt : na, size.auto, i_tcb, text_wrap=text.wrap_auto)

 bline := line.new(kzstart, kzhigh, time, kzhigh, xloc.bar_time, extend.none, bdcol, line.style_solid, 1)

 bline2 := line.new(kzstart, kzlow, time, kzlow, xloc.bar_time, extend.none, bdcol, line.style_solid, 1)

 dtext = dow4 == 1 ? "Sun • " : dow4 == 2 ? "Mon • " : dow4 == 3 ? "Tue • " : dow4 == 4 ? "Wed • " : dow4 == 5 ? "Thu • " : dow4 == 6 ? "Fri • " : dow4 == 7 ? "Sat • " : na

 rtext = dtext + str.tostring(forex ? math.round(pip(tgdist)) : math.round_to_mintick(tgdist)) + (forex ? " pips" : " pts")

 if i_pips

 _lbl := label.new(kzstart + dol, kzhigh, rtext, xloc.bar_time, yloc.price, na, textcolor = i_txtcol, size = size.normal,textalign = text.align_right, style=label.style_none)

 if i_kzmid

 bline3 := line.new(kzstart, math.avg(kzhigh,kzlow), time, math.avg(kzhigh,kzlow), xloc.bar_time, extend.none, bdcol, line.style_dashed, 1)

 tz = time - time[1]

 if i_dev and not in_session(kz) and in_session(kz)[1] and x

 for s = 1 to i_devno by 1

 _hline(kzstart, time - 1 * tz, kzhigh[1] + devdiff * s, bdcol, line.style_solid, 1)

 _hline(kzstart, time - 1 * tz, kzlow[1] - devdiff * s, bdcol, line.style_solid, 1)

if disp and i_rshow

 ictbox(asia, i_vasia, "Asia", i_bool2)

 ictbox(cbdr, i_vcbdr, "CBDR", i_bool1)

 ictbox(london, i_vlon, "London", i_bool3)

 ictbox(nysesh, i_vny, "NY", i_bool4)

 ictbox(lcsesh, i_lc, "London \n Close", i_bool5)

if i_vline and nymid == nymid and disp

 line.new(nymid + dow, high, nymid + dow, low, xloc.bar_time, extend.both, i_vcol, vstyle, 1)

//END
